过充电压：4.275±25mV（过充电压可调整，每次步进10mV，最大值4.6v，支持4.2V-4.5V平台）
1，静态工作电流; 0.5uA，MAX=0.8uA
2，关机电流：1nA
3,充电过流：可调（默认是放电电流2倍）
4，放电过流：可调（最低30mA，默认最大0.15A，中测可调最大默认值，最大不大于0.5A）
6，过放电压：2.8V±35mV
7 ，管压降0V
8,带负载防电芯反接：0V可充支持带负载电芯反接
9，ESD:8000V
10,短路保护：可调，随放电过流值调整
The XBL60152-ADJ Series product is a
high integration solution for lithium-ion/poly
-mer battery protection. XBL60152-ADJ Se
-ries contains advanced power MOSFET,
high-accuracy voltage detection circuits an
-d delay circuits. XBL60152-ADJ Series is
put into an DFN1X1x0.37-4 package make
-s it an ideal solution in limited space of ba
-ttery pack.
XBL60152-ADJ Series has all the protect
-ion functions required in the battery applic
ation including overcharging, overdischargi
-ng, overcurrent and load short circuiting pr
-otection etc. The accurate overcharging
detection voltage ensures safe and full utili
zation charging. The low standby current dr
-ains little current from the cell while in stor
-age.
The device is not only targeted for digital
cellular phones, but also for any other Li-Io
-n and Li-Poly battery-powered information
appliances requiring long-term battery life.
FEATURES
Protection of Battery Cell Reverse
Connection with external load
Support all pin rosin joint
Integrate Advanced Power MOSFET
with Equivalent of 52mΩ RSS(ON)
DFN 1x1x0.37-4Package
Reverse Connection of Charger is
Supported
Low Overcharge Release Voltage
Overdischarge Current 1 Protection
0.15A
Charger Detection Function
0V Battery Charging Function
Delay Times are generated inside
High-accuracy Voltage Detection
Low Current Consumption
-Operation Mode:0.5μA typ.
-Power-down Mode: 1nA typ.
RoHS Compliant and Lead (Pb) Free
APPLICATIONS
One-Cell Lithium-ion Battery Pack
Lithium-Polymer Battery Pack
Wearable Device
Bluetooth Earphone
